Vehicle Details:
Chrome front bumper w/glossy body-color top cover
Chrome rear bumper
Black lower air dam
Front fender vents
Black box-rail & tailgate top-edge moldings
Grille w/medium platinum insert & chrome surround
Dual beam jewel effect headlamps
Fog lamps
Pickup box/cargo lights
Underhood service light
Black door handles
Solar tinted windshield & front door glass
Rear door & window privacy glass
Interval windshield wipers
Front license plate bracket *Standard in states where required. Optional in all other states.*
Rear license plate bracket
Removable locking tailgate w/black handle & Tailgate Assist
Driver & front passenger manual lumbar support
FlexFold 60/40 rear bench seat w/fold-flat feature, grocery hooks, dual cupholders, tray, steel load floor
Color-keyed carpet full-floor covering
Color-keyed scuff plates
Black leather-wrapped steering wheel w/audio & climate controls
Tilt steering wheel
SecuriLock anti-theft ignition
Tire pressure monitoring system
Pwr windows w/driver one-touch-down & backlit switches
Accessory delay
Cruise control
Dual zone electronic automatic temperature control (EATC)
(4) air registers w/positive shut-off
Auxiliary pwr point
Dash-top tray
Glove box
Ashtray & cigar lighter
Instrument panel mounted storage bin & trash bag hook
Electrochromic rearview mirror w/compass
Color-keyed cloth headliner
Front passenger-side roof ride handle
Rear seating roof ride handles
Driver & passenger grab handles
Rear seat LH/RH grab handles
Front door operated dome lamp w/time delay off & IP switch
Dual color-keyed cloth sunvisors-inc: driver-side map strap, dual covered lighted mirrors
Dual color-keyed coat hooks
Stationary elevated engine idle control (SEIC)
Engine block heater *Standard in AK, CO, IA, ID, ME, MI, MN, MT, ND, NH, NY, SD, VT, WI & WY. Optional in all other states.*
2-speed transfer case w/manual locking front hubs
4.10 axle ratio
4-wheel drive
72 amp/hr (650 CCA) battery
115-amp HD alternator
Trailer tow pkg-inc: 7-wire harness w/relays, 7/4 pin combination connector, trailer brake wiring kit w/o controller
Class V trailer hitch receiver-inc: 2" hitch
Mono-beam front axle w/coil spring suspension
HD gas shock absorbers
Front stabilizer bar
2-ton mechanical jack
Pwr steering
Driver & front passenger airbags
Color-keyed safety belts w/front seat outboard height adjustable D-rings
BeltMinder seatbelt-not-buckled chime & flashing warning light
Child seat tethers on all rear passenger seats
Vehicle Name: Ford Super Duty F-250 SRW
Body Style: Crew Cab 6-3/4'
Body Code: 156" WB
Drivetrain: 4-Wheel Drive
Passenger Capacity: 6
Gross Axle Wt Rating - Front: 4800
Gross Axle Wt Rating - Rear: 6100
Curb Weight - Front: 4659
Curb Weight - Rear: 2851
Gross Vehicle Weight Rating Cap: 10000
EPA Fuel Economy Est - City:
EPA Fuel Economy Est - Hwy:
Gross Combined Wt Rating: 23000
Dead Weight Hitch - Max Trailer Wt.: 5000
Dead Weight Hitch - Max Tongue Wt.: 500
Wt Distributing Hitch - Max Trailer Wt.: 12500
Wt Distributing Hitch - Max Tongue Wt.: 1875
Fifth Wheel Hitch - Max Trailer Wt.: 15200
Fifth Wheel Hitch - Max Tongue Wt.: 3800
Engine Order Code: 99R
Engine Type: Diesel V8
Displacement: 6.4L/- TBD -
Fuel System: Turbo-Charged OHV
SAE Net Horsepower @ RPM: 350 @ 3000
SAE Net Torque @ RPM: 650 @ 2000
Trans Order Code: 445
Trans Type: 6
Trans Description Cont.: HD Manual w/OD
Trans Description Cont. Again:
First Gear Ratio (:1): 5.79
Second Gear Ratio (:1): 3.30
Third Gear Ratio (:1): 2.10
Fourth Gear Ratio (:1): 1.30
Fifth Gear Ratio (:1): 1.00
Sixth Gear Ratio (:1): 0.72
Reverse Ratio (:1): 5.23
Clutch Size: 11.9
Trans Power Take Off:
Trans PTO Access:
Transfer Case Model: New Venture 271
Transfer Case Gear Ratio (:1), High: 1.00
Transfer Case Gear Ratio (:1), Low: 2.72
Transfer Case Power Take Off:
Cold Cranking Amps @ 0° F (Primary): 750
Cold Cranking Amps @ 0° F (2nd): 750
Maximum Alternator Capacity (amps): HD 135
Maximum Alternator Watts: 1950
Total Cooling System Capacity: 28.5
Engine Oil Cooler: - TBD -
Frame Type: Ladder-Type
Suspension Type - Front: Coil
Suspension Type - Rear: 2-Stage Leaf
Spring Capacity - Front: 4000
Spring Capacity - Rear: 6100
Axle Type - Front: Dana 60 Monobeam
Axle Type - Rear: Visteon Full-Floating
Axle Capacity - Front: 6000
Axle Capacity - Rear: 6200
Axle Ratio (:1) - Front: 4.10
Axle Ratio (:1) - Rear: 4.10
Shock Absorber Diameter - Front: 35
Shock Absorber Diameter - Rear: 35
Stabilizer Bar Diameter - Front: - TBD -
Stabilizer Bar Diameter - Rear:
Front Tire Order Code: TJB
Rear Tire Order Code: TJB
Spare Tire Order Code: TJB
Front Tire Size: LT275/70R18E
Rear Tire Size: LT275/70R18E
Spare Tire Size: LT275/70R18E
Front Tire Capacity: 3640
Rear Tire Capacity: 3640
Spare Tire Capacity: 3640
Revolutions/Mile @ 45 mph - Front: 627
Revolutions/Mile @ 45 mph - Rear: 627
Revolutions/Mile @ 45 mph - Spare: 627
Front Wheel Size: 18 x 8.0
Rear Wheel Size: 18 x 8.0
Spare Wheel Size: 18 x 8.0
Front Wheel Material: Aluminum
Rear Wheel Material: Aluminum
Spare Wheel Material: Steel
Steering Type: Pwr
Steering Ratio (:1), On Center: 17.0
Steering Ratio (:1), At Lock: - TBD -
Turning Diameter - Curb to Curb: 51.8
Turning Diameter - Wall to Wall: 53.7
Brake Type: Pwr
Brake ABS System: 4-Wheel
Brake ABS System (Second Line):
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Front Brake Rotor Diam x Thickness: 13.66 x 0.58
Rear Brake Rotor Diam x Thickness: 13.39 x 0.47
Drum - Rear (Yes or ):
Rear Drum Diam x Width:
Fuel Tank Capacity, Approx: 30.5
Aux Fuel Tank Capacity, Approx:
Fuel Tank Location: Midship
Aux Fuel Tank Location:
Front Head Room: - TBD -
Front Leg Room: - TBD -
Front Shoulder Room: - TBD -
Front Hip Room: - TBD -
Second Head Room: - TBD -
Second Leg Room: - TBD -
Second Shoulder Room: - TBD -
Second Hip Room: - TBD -
Wheelbase: 156.2
Length, Overall w/o rear bumper: 246.2
Width, Max w/o mirrors: 79.9
Height, Overall: 79.3
Overhang, Front: 37.6
Overhang, Rear w/o bumper: 52.4
Front Bumper to Back of Cab: 154.3
Cab to Axle: 39.9
Cab to End of Frame: 80.2
Ground to Top of Load Floor: 34.7
Ground to Top of Frame: - TBD -
Frame Width, Rear: 36.5
Ground Clearance, Front: - TBD -
Ground Clearance, Rear: 8.1
Cargo Box Length @ Floor: 81.8
Cargo Box Width @ Top, Rear: 63.6
Cargo Box Width @ Floor: 60.6
Cargo Box Width @ Wheelhousings: 50.9
Cargo Box (Area) Height: 20.1
Tailgate Width: 60.6
Cargo Volume: 64.4
Ext'd Cab Cargo Volume:
Country of Origin: United States Ford
Stationary elevated engine idle control (SEIC)
Engine block heater *Standard in AK CO IA ID ME MI MN MT ND NH NY SD VT WI & WY. Optional in all other states.*
2-speed transfer case w/manual locking front hubs
4.10 axle ratio
4-wheel drive
72 amp/hr (650 CCA) battery
115-amp HD alternator
Trailer tow pkg-inc: 7-wire harness w/relays 7/4 pin combination connector trailer brake wiring kit w/o controller
Class V trailer hitch receiver-inc: 2" hitch
6-3/4' pickup box-inc: (4) tie-down hooks partitionable & stackable storage
Mono-beam front axle w/coil spring suspension
HD gas shock absorbers
Front stabilizer bar
2-ton mechanical jack
Pwr steering
Chrome front bumper w/glossy body-color top cover
Chrome rear bumper
Black lower air dam
Front fender vents
Black box-rail & tailgate top-edge moldings
Grille w/medium platinum insert & chrome surround
Dual beam jewel effect headlamps
Fog lamps
Pickup box/cargo lights
Underhood service light
Black Door Handles
Solar tinted windshield & front door glass
Rear door & window privacy glass
Interval windshield wipers
Front license plate bracket *Standard in states where required. Optional in all other states.*
Rear license plate bracket
Removable locking tailgate w/black handle & Tailgate Assist
Driver & front passenger manual lumbar support
FlexFold 60/40 rear bench seat w/fold-flat feature grocery hooks dual cupholders tray steel load floor
Color-keyed carpet full-floor covering
Color-keyed scuff plates
Black leather-wrapped steering wheel w/audio & climate controls
TILT STEERING WHEEL
Securilock anti-theft ignition
Tire pressure monitoring system
Pwr windows w/driver one-touch-down & backlit switches
Accessory delay
Cruise Control
Dual zone electronic automatic temperature control (EATC)
(4) air registers w/positive shut-off
Auxiliary pwr point
Dash-top tray
Glove Box
Ashtray & cigar lighter
Instrument panel mounted storage bin & trash bag hook
Electrochromic rearview mirror w/compass
Color-keyed cloth headliner
Front passenger-side roof ride handle
Rear seating roof ride handles
Driver & passenger grab handles
Rear seat LH/RH grab handles
Front door operated dome lamp w/time delay off & IP switch
Dual color-keyed cloth sunvisors-inc: driver-side map strap dual covered lighted mirrors
Dual color-keyed coat hooks
Driver & front passenger airbags
Color-keyed safety belts w/front seat outboard height adjustable D-rings
BeltMinder seatbelt-not-buckled chime & flashing warning light
Child seat tethers on all rear passenger seats
Driver Air Bag
Passenger Air Bag
Climate Control
Multi-Zone A/C
A/C
AM/FM Stereo
CD Player
ABS
4-Wheel Disc Brakes
Four Wheel Drive
8 Cylinder Engine
Turbocharged
Floor Mats
Diesel Fuel
Keyless Entry
Power Door Locks
Power Mirror(s)
Running Boards/Side Steps
Power Driver Seat
Power Passenger Seat
Pass-Through Rear Seat
Leather Seats
Power Steering
Adjustable Steering Wheel
Conventional Spare Tire
Aluminum Wheels
Power Windows
Intermittent Wipers
Fog Lamps
Privacy Glass
Steering Wheel Audio Controls
Power Outlet
Immobilizer
Automatic Headlights
Woodgrain Interior Trim
Auto-Dimming Rearview Mirror
Driver Vanity Mirror
Passenger Vanity Mirror
Driver Illuminated Vanity Mirror
Passenger Illuminated Visor Mirror
Front Reading Lamps
Rear Reading Lamps
Driver Adjustable Lumbar
Passenger Adjustable Lumbar
Leather Steering Wheel
Tow Hitch
Tow Hooks
Tire Pressure Monitor
Trip Computer
Universal Garage Door Opener
Sliding Rear Window
Auxiliary Audio Input
Rear Bench Seat
